【摩尔资讯】印度尼西亚采用 Wi-Fi 6E 技术

Radio frequency

spectrum

Effective lsotropic radiated power (EIRP)

Bandwidth

Location of the device

5925-6425 MHz

Access type 1: low power indoor (LPl) 200mW (23 dBm)

320 MHz

Indoor use.

Outdoor use is forbidden

Access type 1: very low power indoor (VLP) 25 mW (14 dBm)

indoor and outdoor use

Radio frequency spectrum

Maximum transmit power and/or Maximum field strength

315-405 kHz

In accordance with applicable technical standards

1700-1800 kHz

5925-6425 MHz

Test requirements / characteristics

Test requirements / characteristics

Electrical safety

1. SNI IEC 60950-1
2. SNI IEC 62368-1
3. IEC 62368-1
4. IEC 60950-1

And other relevant lEC or SNl standards

EMS (emission)

1. ETSI EN 301 489-1 and/or ETSI EN 301489-17
2. IEC CISPR 32 and /or
3. SNI CISPR 32

EMS (immunity)

Test methods for immunity requirements are stipulated in a separate ministerial decree

Radio frequency

RF Output power

Channel Bandwidth

Spurious Emission

1. EN 300 328 (the early version is 1.8.1)
2. EN 301 893 (the early version is 1.7.1)
3. EN 302 502 (the early version is 1.2.1)or
4. EN 300 440

Out-of-band emissions

1. EN 300 328 (the early version is 1.8.1)
2. EN 301 893 (the early version is 1.7.1) or
3. EN 302 502(the early version is 1.2.1)
